SKU:LH86WAFPLGCXUE
Warranty : Standard 3 Years
In stock
Specifications
| Diagonal size | 86″ |
| Panel type | IPS |
| Resolution | 3840 × 2160 |
| Pixel pitch (H×V) | 0.493 × 0.493 mm |
| Brightness (typ.) | 450 nit |
| Contrast ratio | 1200:1 |
| Viewing angle (H/V) | 178° / 178° |
| Response time | 8 ms |
| Color gamut | 72% |
| Glass haze | 25% |
| Horizontal scanning frequency | 135 kHz |
| Maximum pixel frequency | 78 MHz |
| Vertical scanning frequency | 60 Hz |
| Operation time support | 12/7 |
| HDMI inputs | 2 |
| DisplayPort input | 1 |
| HDMI version | 2.1 |
| DisplayPort version | 1.2 |
| HDCP version | 2.2 |
| USB ports | 4 |
| IR input | No |
| Audio input | Stereo mini jack |
| Audio output | Stereo mini jack |
| Video output | Yes |
| RS232 input | Yes |
| RJ45 input | Yes |
| RJ45 output | Yes |
| Wi-Fi | Wi-Fi 6 (802.11ax) |
| Bluetooth | Yes |
| Power supply | AC 100–240 V, 50/60 Hz |
| Power consumption (on) | 529 W |
| Power consumption (sleep) | 0.5 W |
| Set dimensions (W×H×D) | 1950.4 × 1174.0 × 87.1 mm |
| Package dimensions (W×H×D) | 2095 × 1265 × 185 mm |
| Set weight | 60.9 kg |
| Package weight | 71.8 kg |
| Operating temperature | 0 – 40 °C |
| Operating humidity | 10–80% (non-condensing) |
| VESA mount | 800 × 600 mm |
| Bezel width | 14.9 mm |
| Bezel color | Top/Bottom: Dark blue-gray, Side: Black |
| Frame material | Aluminium |
| Touch support | Yes |
| Operating system | Android 15 |
| Flash memory | 128 GB |
| Touch technology | IR |
| EMC compliance | FCC CFR Title 47 Part 15 Subpart B / EN55032:2015+A11:2020 |
| Safety | IEC62368-1 / UL62368-1 / IEC60950-1 / IS13252 |
